Introducing the redesigned FlowKooler Water Pump, featuring state-of-the-art CNC machined billet impeller blades that now boast 16 blades—double the amount of most standard water pumps. This innovative design significantly enhances flow rates and improves block pressure, ensuring your engine operates at optimal temperatures.
The pump is coated with a Type II Class II military-grade anodized surface, providing excellent protection against electrolysis and corrosive fluids. With tighter clearances between the impellers and incremental vanes, this water pump maintains consistent pressure, allowing coolant to flow efficiently and keeping your engine cool even in the most demanding conditions.
This new design increases block pressure by up to 22%, reducing hot spots on cylinder walls and preventing pockets of steam within the engine block. Additionally, the vane configuration can increase horsepower by up to 2.2%, enhancing your FSJ's overall performance.
By lowering engine temperatures by as much as 30 degrees, this water pump helps extend engine life and minimizes premature wear. At idle, it doubles the coolant flow compared to standard pumps and provides 20% more flow than high-volume alternatives, ensuring effective radiator function even at low speeds up to 3,500 RPM. This extra flow at idle promotes continuous circulation of coolant, preventing build-up in the heater core and radiator after the thermostat opens.
In short, we believe this is the ultimate water pump for your Grand Wagoneer, Full Size Jeep, or J-Series Truck equipped with AMC V8 engines. Experience the difference in cooling performance and engine efficiency with the FlowKooler Water Pump!
Highlights:
- CNC Machined aluminum impeller with 16 vanes
- Protected with a military grade Type II Class II surface coating
- Impeller chamber is directional to clockwise rotation
- Lower radiator hose exits left front side (driver's side)
- Fits American Motors, Jeep products
- Mounting Gaskets, Installation Sheet, FlowKooler Decal Included
Fits the following with AMC V8 Engine:
- 1973-1983 Wagoneer
- 1974-1983 Cherokee
- 1984-1991 Grand Wagoneer
- 1973-1988 J-Series Trucks
General Specifications: |
|
Type of Material of Pump Body |
Aluminum |
Number of Blades on Impeller |
8 CNC Aluminum |
Direction of Rotation |
CW |
Fan Hub Working Height |
4-13/16" |
Shaft Diameter |
5/8" |
Inlet Outside Diameter |
1 7/8" |
Fan hub thread |
5/16-24" |
Hose Connections: |
1st |
2nd |
Gender |
M |
M |
Diameter |
7/8" |
7/8" |
Threaded |
NA |
NA |
