Restored 7 Blade Fan with New Clutch for Full Size Jeep (1973-1991) with AMC 304, 360, 401 Engines
$255.00
Enhance your Jeep's engine cooling efficiency with our Ultimate Jeep Engine Cooling Fan. Thi
New
click to zoom in
FlowKooler
1973-1991 Jeep AMC 304 360 401 High Flow Aluminum Water Pump
(No reviews yet)
Write a Review
Weight:
5.00 LBS
$159.99
#SAVETHEFULLSIZEJEEP
A Portion Of The Proceeds From Your Purchase Supports The Development & Reproduction Of High Quality 1963-1991 Restoration Parts.
1973-1991 Jeep AMC 304 360 401 High Flow Aluminum Water Pump
$159.99
Introducing the redesigned FlowKooler Water Pump, featuring state-of-the-art CNC machined billet impeller blades that now boast 16 blades—double the amount of most standard water pumps. This innovative design significantly enhances flow rates and improves block pressure, ensuring your engine operates at optimal temperatures.
The pump is coated with a Type II Class II military-grade anodized surface, providing excellent protection against electrolysis and corrosive fluids. With tighter clearances between the impellers and incremental vanes, this water pump maintains consistent pressure, allowing coolant to flow efficiently and keeping your engine cool even in the most demanding conditions.
This new design increases block pressure by up to 22%, reducing hot spots on cylinder walls and preventing pockets of steam within the engine block. Additionally, the vane configuration can increase horsepower by up to 2.2%, enhancing your FSJ's overall performance.
By lowering engine temperatures by as much as 30 degrees, this water pump helps extend engine life and minimizes premature wear. At idle, it doubles the coolant flow compared to standard pumps and provides 20% more flow than high-volume alternatives, ensuring effective radiator function even at low speeds up to 3,500 RPM. This extra flow at idle promotes continuous circulation of coolant, preventing build-up in the heater core and radiator after the thermostat opens.
In short, we believe this is the ultimate water pump for your Grand Wagoneer, Full Size Jeep, or J-Series Truck equipped with AMC V8 engines. Experience the difference in cooling performance and engine efficiency with the FlowKooler Water Pump!
Highlights:
- CNC Machined aluminum impeller with 16 vanes
- Protected with a military grade Type II Class II surface coating
- Impeller chamber is directional to clockwise rotation
- Lower radiator hose exits left front side (driver's side)
- Fits American Motors, Jeep products
- Mounting Gaskets, Installation Sheet, FlowKooler Decal Included
Fits the following with AMC V8 Engine:
- 1973-1983 Wagoneer
- 1974-1983 Cherokee
- 1984-1991 Grand Wagoneer
- 1973-1988 J-Series Trucks
| General Specifications: | ||
| Type of Material of Pump Body | Aluminum | |
| Number of Blades on Impeller | 8 CNC Aluminum | |
| Direction of Rotation | CW | |
| Fan Hub Working Height | 4-13/16" | |
| Shaft Diameter | 5/8" | |
| Inlet Outside Diameter | 1 7/8" | |
| Fan hub thread | 5/16-24" | |
| Hose Connections: | 1st | 2nd |
|---|---|---|
| Gender | M | M |
| Diameter | 7/8" | 7/8" |
| Threaded | NA | NA |
Flow Kooler offers a 2-year warranty, as long as the part has not been altered, misused, or used in racing applications.
To submit a return or exchange request, please go to our Contact Us page to submit order information. Photos of any damaged products may be requested and required to process any full or partial refund. If approved, we will provide you with an RMA number along with a return label for shipping.
Parts returned that are not defective, are subject to a 25% restocking charge. JeepRecyclers.com/McDaniel Motor Co. is NOT responsible for any parts that have been altered, modified, disassembled, or damaged by misuse or an accident subsequent to the parts purchase.
Reconditioned parts come with a minimum warranty of 90 days, unless otherwise stated (Refer to product listing for warranty duration). The warranty is void if the parts are not returned in the same condition in which they are sold. Warranties for aftermarket parts are covered by the manufacturer.
