1988-1991 Grand Wagoneer Downflow Aluminum Radiator AMC V8

(No reviews yet) Write a Review
UPC:
845804061372
Availability:
Ships directly from manufacturer. Ship times may vary.
Weight:
16.80 LBS
$175.80

#SAVETHEFULLSIZEJEEP

A Portion Of The Proceeds From Your Purchase Supports The Development & Reproduction Of High Quality 1963-1991 Restoration Parts.

1988-1991 Grand Wagoneer Downflow Aluminum Radiator AMC V8

1988-1991 Grand Wagoneer Downflow Aluminum Radiator AMC V8

$175.80

Made from premium grade aluminum.The tubes are cadmium plated inside and out to prevent premature failure. Each radiator is individually pressure tested and engineered for multi-fit without compromising the look and fit. OSC Premium New Automotive Radiator is designed to OES form and function. OSC radiators are technically advanced and made from premium grade aluminum. The tubes are cadmium plated inside and out to prevent premature failure. OSC does not substitute aluminum coolers in place of Stainless Steel plate or Copper and Brass concentric coolers and they use a die cut gasket to ensure there are no leaks. Each radiator is individually pressure tested and engineered for multi-fit without compromising the look and fit. All necessary fittings or hardware are included in each unit. All units meet OES cooler design with copper concentric coolers and plate coolers where originally equipped.

Features & Benefits

  • Drop in fit, form and function for hassle-free installation
  • All necessary hardware or fittings are included in each unit
  • 100% Leak Tested
  • Premium grade tubes, fins, headers, tanks, and other components
  • Components are fitted and torqued in place to factory specifications

Fits:

  • 88-91 Jeep Wagoneer with 5.9L 360 V8 Engine
Radiator Material: Aluminum/Plastic
Radiator Style: Downflow
Transmission Cooler: Yes
Overall Width (in.): 32.88 in.
Overall Height (in.): 26.19 in.
Overall Thickness (in.): 4.50
Row Quantity: 1
Radiator Finish: Natural
Core Width (in.): 26.75 in.
Core Height (in.): 18.31 in.
Core Thickness (in.): 1.25 in.
Radiator Inlet Size: 1.500 in.
Radiator Outlet Size: 1.750 in.
Trans Cooler Line Connection: Quick-Disconnect
Trans Cooler Adapter Fittings Included: No
Fan Included: No
Radiator Cap Included: No
