2 Pass 13" Series 7000 Copper/Aluminum Frame Rail Transmission Cooler, 11/32"

(No reviews yet) Write a Review
UPC:
00083277132223
Availability:
This part ships direct from the manufacturer, lead times, stock and shipping may vary.
Weight:
1.94 LBS
$39.89

#SAVETHEFULLSIZEJEEP

A Portion Of The Proceeds From Your Purchase Supports The Development & Reproduction Of High Quality 1963-1991 Restoration Parts.

2 Pass 13" Series 7000 Copper/Aluminum Frame Rail Transmission Cooler, 11/32"

2 Pass 13" Series 7000 Copper/Aluminum Frame Rail Transmission Cooler, 11/32"

$39.89
With the same 1/2" copper tubing expanded into aluminum cooling fins and embossed turbulators as our larger transmission coolers, this cooler uses a slim design to enable frame mounting in limited space applications. This kit comes with a complete transmission cooler hardware kit to easily install onto vehicles with 5/16" transmission cooler lines. Perfect for light-duty use and occasional light towing.

Installation Instructions





ColorBlack
Comments1/2" copper tubing expanded into aluminum cooling fins
Comments11/32" hose barb inlets
Comments2 pass cooler design
CommentsComplete hardware kit included
CommentsEmbossed turbulators inserted in each tube agitate fluid for maximum heat transfer
CommentsExtends life of transmission
CommentsExtruded plastic cooling fin guards
CommentsFluid Capacity: 2.5 oz.
CommentsImproves transmission performance
CommentsPrevents heat related transmission failures
Cooler styleTube & Fin
Core Length9-7/8
Depth1-3/4
Hose length4
Hose size11/32
Inlet dim1-1/4
Inlet size11/32 barb
Length12-7/8
MaterialCopper Tube & Aluminum Fin
Mounting11-3/4
Width2-5/8
