Derale
24 Row Series 8000 Plate & Fin Cooler, 11/32"
UPC:
00083277335044
Availability:
This part ships direct from the manufacturer, lead times, stock and shipping may vary.
Weight:
2.75 LBS
$85.57
#SAVETHEFULLSIZEJEEP
A Portion Of The Proceeds From Your Purchase Supports The Development & Reproduction Of High Quality 1963-1991 Restoration Parts.
24 Row Series 8000 Plate & Fin Cooler, 11/32"
$85.57
A step up from Tube & Fin type coolers, this Plate and Fin cooler features strong furnace-brazed construction, 7/8" wide plates, 3/4" embossed turbulators which maximize heat transfer while also minimizing pressure drop. This unit is perfect for full size cars trucks and SUVs with medium to light-heavy duty use and consistent towing. It greatly extends transmission life by preventing heat-related transmission failures, and improve shifting performance.
| Color | Black |
| Cooler style | Plate & Fin |
| Depth | 7/8 |
| Description_ASC | 11/32" hose barb inlets |
| Description_ASC | 23000 BTU |
| Description_ASC | 24 row cooler design |
| Description_ASC | 3/4" embossed turbulators maximize cooling & minimize pressure drop |
| Description_ASC | Cooler Only |
| Description_ASC | Embossed turbulators inserted in each tube agitate fluid for maximum heat transfer |
| Description_ASC | Extruded plastic cooling fin guards |
| Description_ASC | Fluid Capacity: 8 oz. |
| Description_ASC | Improves transmission performance |
| Description_ASC | Sturdy furnace-brazed aluminum construction |
| Description_DEF | Automatic Transmission Oil Cooler |
| Description_DES | 24 Row Series 8000 Plate & Fin Cooler, 11/32" |
| Description_KEY | plate and fin coolers; plate and fin transmission cooler kits; transmission cooling; transmission components; aluminum coolers, towing accessories; coolers; transmission cooling; stacked plate coolers; transcoolers; heavy duty transcoolers; heavy duty transmission cooler kits |
| Description_MKT | A step up from Tube & Fin type coolers, this Plate and Fin cooler features strong furnace-brazed construction, 7/8" wide plates, 3/4" embossed turbulators which maximize heat transfer while also minimizing pressure drop. This unit is perfect for full size cars trucks and SUVs with medium to light-heavy duty use and consistent towing. It greatly extends transmission life by preventing heat-related transmission failures, and improve shifting performance. |
| GVW | 22500 |
| Height | 11-3/4 |
| Inlet dim | 10-1/4 |
| Inlet size | 11/32 barb |
| Material | Aluminum |
| Mounting | 6-3/4 x 10-1/2 |
| Width | 10-1/8 |
