High Output 17" Electric Puller Fan/Black Steel Shroud Kit

(No reviews yet) Write a Review
UPC:
00083277169199
Availability:
This part ships direct from the manufacturer, lead times, stock and shipping may vary.
Weight:
15.00 LBS
$241.49

#SAVETHEFULLSIZEJEEP

A Portion Of The Proceeds From Your Purchase Supports The Development & Reproduction Of High Quality 1963-1991 Restoration Parts.

High Output 17" Electric Puller Fan/Black Steel Shroud Kit

High Output 17" Electric Puller Fan/Black Steel Shroud Kit

$241.49
A primary cooling fan, this new universal metal-shrouded single H.O. RAD fan features our powerful 17" 2 speed 265 watt Bosch motored fan and surrounds it with a 19-1/2" x 18" x 3 5/8" shroud that allows fitment in a wide range of hot rods and street rods with narrow radiator applications. A puller fan only, the kit includes a high amp relay wire harness, 4 black powder coated mounting brackets and assembly hardware.

Installation Instructions





Amp draw high/low23.5/17.4
CFM high/low2400/1800
ColorBlack
Comments2400 CFM
CommentsDesigned for primary cooling
CommentsFan Kit includes complete mounting kit with single relay wiring harness
CommentsHigh Output 265 watt motor
CommentsPowder coated metal fan shroud
CommentsPuller (engine side) applications only
CommentsUltra-quiet patented skewed blade design
Depth1-5/8
Height18
Mounting8-7/8 x 15-3/4
Overall depth3-5/8
Width19-1/2
