MOOG 1974-1991 Steering Tie Rod End At Pitman Arm

(No reviews yet) Write a Review
UPC:
080066136387
Weight:
1.60 LBS
$55.18

#SAVETHEFULLSIZEJEEP

A Portion Of The Proceeds From Your Purchase Supports The Development & Reproduction Of High Quality 1963-1991 Restoration Parts.

MOOG 1974-1991 Steering Tie Rod End At Pitman Arm

MOOG 1974-1991 Steering Tie Rod End At Pitman Arm

$55.18

Front Steering Tie Rod End At Pitman Arm for 1974-1991 Full Size Jeeps!

3.38 in. stud center to end; 0.88-18L rod thread; Male rod type; 0.68 in. top stud diameter; 0.77 in. bottom stud diameter; 9/16 in.-18 stud thread; Includes hardware


Fits:

  • 1974-1983 Cherokee
  • 1974-1983 Wagoneer
  • 1984-1991 Grand Wagoner
  • 1974-1988 J-Series Trucks

Tie rods are a crucial part of your steering system. When you turn your steering wheel the motion travels through the steering rack, through the tie rods, and finally through your steering arm or spindle. Without tie rods, you wouldn't be able to turn your car. This part is also incredibly important to your vehicle's alignment. If you replace your tie rods, make sure to get an alignment done immediately afterward.

Moog tie rods feature several differences from the OE. One of the more obvious differences is the overall design itself. Whereas many OE tie rods are two-piece assemblies, Moog's tie rods are forged one-piece units. This one-piece design reduces the chance of early wear, increasing the durability of the part as a whole. To protect your tie rod, Moog uses a neoprene-sealed rubber dust boot. This dust boot is resistant to both extreme temperatures and abrasion. The design for this rubber boot includes a small valve to allow for the flushing of old grease and contaminants. In addition to all these other features, Moog crafts their tie rod end using hardened full-ball metal studs. These hardened studs can stand up to much more than the OE, making the tie rod that much more dependable.

To submit a return or exchange request, please go to our Contact Us page to submit order information. Photos of any damaged products may be requested and required to process any full or partial refund. If approved, we will provide you with an RMA number along with a return label for shipping.

Parts returned that are not defective, are subject to a 25% restocking charge. JeepRecyclers.com/McDaniel Motor Co. is NOT responsible for any parts that have been altered, modified, disassembled, or damaged by misuse or an accident subsequent to the parts purchase.

Reconditioned parts come with a minimum warranty of 90 days, unless otherwise stated (Refer to product listing for warranty duration). The warranty is void if the parts are not returned in the same condition in which they are sold. Warranties for aftermarket parts are covered by the manufacturer.
